Pharma Grade Rigid PVC Film

  • Width: 80--800 mm;
  • Thickness: 200--500 mic;
  • Core ID: 76 mm, cardboard or plastic;
  • Color: transparent, ambar, white, red, green, blue, etc.;
  • Packing: PE bag + carton or plywood pallet. Inquiry
Pharma Grade Rigid PVC Film

Advantage of Pharma Grade Rigid PVC Film

Pharma Grade Rigid PVC Film

Transparent PVC Rigid Film for pharmaceuticals

Rigid PVC is strong, economical and safe, considered as the ideal material for most retail blister packages.

Alu-PVC blister pack is very popular in our daily life, such as for OTC oval drugs (over-the-counter) and other small-size dose, chewing gums, dragees, small-piece foods, etc., whereby the rigid PVC is formed to be blisters by heating, then to seal with the aluminum lidding foil on blister packaging machine.

Tiptop’s PVC film is manufactured by the proven technology, the qualified materials, the state-of-the-art machines and skilled workers to meet the high quality requirements of the pharmaceutical & food Industry, and it is registered and active in China FDA now.

Pharma grade rigid PVC film is almost universally produced on a calendar, a “rigid” or “un-plasticized” material, with low residual monomer content and tailored shrink profiles.

Normally the mono PVC is transparent (clear), which makes the encased product perfectly visible to the consumer, and provides reassurance that the product amount is as advertised or prescribed by doctor.

Specification of Pharma Grade Rigid PVC Film

Normally the gauges 200mic (7.5mils) and 250mic (10mils) offer sufficient material to form blisters of a size that conventional tablets, pills, and capsules can be placed in them and pushed out of the blister. But for duplex doses, soft gelatin capsule, chewing gums, etc, heavy film shall be used, like 300mic (12mils), even 400mic (16mils). They all are available in Tiptop.

Here is regular specification of pharmaceutical usage PVC rigid film in Tiptop:

Product code Structure Thickness Weight Max. width
TTF-PVC-1 200mic 200±20mic 276±27gsm 800mm
TTF-PVC-2 250mic 250±20mic 345±27gsm 800mm
TTF-PVC-3 300mic 300±20mic 414±27gsm 800mm
TTF-PVC-4 320mic 320±20mic 442±27gsm 800mm

Please kindly be noted: other thickness is also available.

Colored mono PVC film

Colored Rigid PVC Films

Colored Rigid PVC Films for blister packaging

Mono PVC also can be colored with pigment, such as red, amber, white, green, etc., to resiste the visible light, which is one good choice for light-sensitive products.

Meanwhile the PVC with UV filters is availiable in Tiptop, to to resiste the UV rays, which is better barrier for medicines consumed in the areas with rich sun shines.

Tiptop is able to do the opaque PVC blister film as your request. In this case, it is best that you could offer us the original colored sample to prepare our sample for you to test and confirm the quality before the bulk production. Otherwise we could directly offer our colored sample; you check its color and do machine trial, then feedback to Tiptop.

Our pharma grade rigid PVC film is being produced of pharmaceutical grade resins, in clean room meeting all GMP requirements. The whole production progress is traceable: each batch of goods is with records of raw materials, production & QA/QC, test & release, delivery, etc, which will be kept at least 3 years.

Please kindly be noted: it will take 5-7days to prepare the sample.

Based on more costs during production, the colored PVC price will be a little higher. For exact one, please inquiry me now.

Packing of Pharma Grade Rigid PVC Film:

for silted rolls:

Carton Pack

Carton Pack

1.1 each roll is sealed in PE bag, loaded into carton. Cartons stack into shipment container directly.

Aproxi 16-20tons for one 20ft FCL load, which depends on roll widths & weight.

1.2 each roll is sealed in PE bag, loaded into carton. Cartons stack on plywood pallet, with four edge protectors and plastic film wrapping.

Aproxi 16-18tons for one 20ft FCL load, it depends on the width & weight of each roll.

for jumbo rolls:



roll is wrapped by PE film and Kraft, with two edge protectors, then stack on plywood pallet by eye-to-sky, and covered by plastic film.

Aproxi 16-20tons for one 20ft FCL load, it depends on the width & weight of each roll.

They both are strong enough and an effective shield against the dusts or damages during shipment to your company,
